MATERIALS OF CONSTRUCTION

Carbon steel
(ISO 15608 - group 1)

  • SA516 Gr60 / 70
  • P265 GH / P355 GH

Austenitic stainless steel
(ISO 15608 - group 8)

  • 1.4307 / 304L
  • 1.4404 / 316L
  • 1.4539 / 904L - Resistant to non-oxidizing acids

Austenitic – ferritic
(ISO 15608 - group 10)

  • Duplex / 1.4462 - resistant to pitting corrosion
  • Super duplex / 1.4410 - Resistant to chloride

Nickle based alloy
(ISO 15608 - group 43)

  • Hastelloy C22 /C276 /2.4602
    Resistant to mixture of acids (ox/red), pitting corrosion

WELDING COMPONENTS

Alteco performs certified welding for third parties according to different welding procedures. If required, a complete welding book will be drawn up. Alteco employs certified welders who all have various WPQs. We can rely on a whole range of in-house PQRs, and we draft the necessary WPS for each project.

Image placeholder
Image placeholder
Image placeholder

Pressure & storage vessels

  • Single wall vessels
  • Cooled or heated vessels by use of jacket or (half-)coil
  • Insulation jacket
  • Process Columns
Image placeholder

3D DESIGN: Pressure vessel with internal spargers

Image placeholder

3D DESIGN: cooler (removable U-bundle)

Image placeholder

Example of general arrangement drawing

HEAT EXCHANGERS

  • Shell & tube heat exchangers
  • Fixed bundle
  • Removable bundle
  • Floating head types
  • Replacing tubes of existing heat exchangers
Image placeholder

Cooler - Design acc. EN13445
Volume: 18,4 m³ / 2,6 m³
Material: 1.4541

Image placeholder

Drum water trap - Design acc. ASME VIII div 1
Material: SA106GrB Volume: 300 L

Image placeholder

Example of NDE:
Shells an top head fully welded Penetrant test & protection of polished shell plate

Sheet metal work and machine operations

Image placeholder
Image placeholder
Image placeholder
